Technical Info Super Slim In Wall Basin Hanging Frame (53B)

PRODUCT IDENTIFICATION
Slim basin frame kit (53B) frame for wall hung wash-basin installation.

FRAME APPLICATIONS
- Installation in masonry walls.
- Suitable for renovating projects.

TECHNICAL STRUCTURE FEATURES
- Galvanized metal frame corrosion resistant

ACCESSORIES
- 1 HDPE outlet bend
- 1 Metal ring for outlet bend fixing
- 1 Rubber ring for outlet bend fixing
- 2 Screws TCIC M5X25
- 1 Protective plug
- 1 Inlet gasket ø 46
Fixing accessories for wall structure:
- 4 Fischer dowel screws and washers.

FATIGUE RESISTANCE
- 400 kg static weight supported complies with NF D 12-208 standard.

WARRANTY
Ten years warranty (10 years) according to the general selling terms, warranty starts from the purchasing date of the products. If the product is not correctly installed the warranty is not valid.

INFO
For further information please telephone 01722 415000
