Technical Info Super Slim Bidet Mounting Frame (53G)

Technical Info Super Slim Bidet Mounting Frame (53G)

Click for technical & installation information on slim bidet hanging frames, allowing for space saving and the safe and quick hanging of wall hung and wall mounted bidets.

View Full Description
View Product Features
View PDF Downloads
PRODUCT IDENTIFICATION
Super slim Bidet Installation Frame (53G) structure for wall hung bidet installation.
APPLICATIONS
- Installation in masonry walls.
- Installation in gypsum walls.
- Installation in wooden walls
- Suitable for renovating projects.

TECHNICAL STRUCTURE FEATURES
- Structure in painted tubular corrosion resistant.

ACCESSORIES EQUIPMENT
- 1 PHED discharge pipe bend.
- 1 Metal ring for outlet bend fixing.
- 1 Rubber ring for outlet bend fixing.
- 2 Screw TCIC M5 x 25
- 1 Protective cover;
- 1 Inlet gasket ø 46
- 2 flanged connections ½”G M-F and screws.
- 2 gaskets for flanged connections.
Fixing accessories for wall structure:
- 4 Fischer screws and washers.
- 4 angle metal bracket.
- 2 Fast Fit fixing.
Fixing accessories for bidet mounting on the structure:
- 2 threaded rods M12
- 2 nuts M12
- 2 protection for threaded rod.
- 2 protection cover.
- 2 centering washer.
- 2 Washers Zn ø 34

PROPERTIES
- Height regulation of the adjustable floor brackets (0-200 mm);
- Easy fastening system.

FATIGUE RESISTANCE
400 kg static weight supported complies with NF D 12-208 standard.

WARRANTY
Ten years warranty (10 years) according to the general selling terms, warranty starts from the purchasing date of the products. If the product is not correctly installed the warranty is not valid.

INFO
For further information please telephone 01722 415000
